Epson FX-2190 Service Manual

EPSON FX-890/2190 Revision B
PRODUCT DESCRIPTIONS Interface 27
1.2.4 Optional Interface
Type-B optional interface cards are available.
1.2.5 Type-B Interface communication specification
 Reply for Optional command
(*: Reply for Type-B I/F Level 2 device: not described in user's manual)
Table 1-29. FX-890
Reply message ESC/P IBM PPDS
Main-Type
MT9p, PW80c110cpi,
PRG(Wxxxxx)rev, AP500ma
MT9p, PW80c110cpi,
PRG(Wxxxxx)rev, AP500ma
Product-Name FX-890 FX-890
Emulation-Type ESCP9, PRPII9, BDC ESCP9, PRPII9, BDC
Entity-Type EPSONFX EPSONPRPII9
Table 1-30. FX-2190
Reply message ESC/P IBM PPDS
Main-Type
MT9p, PW136c110cpi,
PRG(Wxxxxx)rev, AP500ma
MT9p, PW136c110cpi,
PRG(Wxxxxx)rev, AP500ma
Product-Name FX-2190 FX-2190
Emulation-Type ESCP9, PRPII9, BDC ESCP9, PRPII9, BDC
Entity-Type EPSONFX EPSONPRPII9
Table 1-31. Reply for Optional command
Option command
number
Command name Reply-A Reply-B
00h No-operation ----- -----
01h Start Hardware Reset Accept* Execute OK*
02h Start Software Reset Reject -----
03h Send Main System Type Accept Execute OK
04h Send Name Data Reject -----
05h Inquire Name Data Accept Execute OK
06h Send Product Name Accept Execute OK
07h Send Software Emulation Type Accept Execute OK
08h Complete Buffered Data Accept Execute OK
09h Stop Procedure Reject -----
0Ah Return Buffered Data Reject -----
0Bh Send Entity Type Accept Execute OK
0Ch Send Status Accept Execute OK
0Dh Quit Procedure Reject -----
0Eh Inquire ASCII Message Reject -----
0Fh Send ASCII Message Accept Execute OK
10h (Reserved) Unknown -----
11h Send All Entity Type Reject -----
12h Inquire Protocol Reject -----
13h (Reserved) Unknown -----
14h Inquire Emergency Message Accept Execute OK
15h Send Emergency Reply Accept Execute OK
16h-17h (Reserved) Unknown -----

Epson FX-2190 Specifications

General

Maximum print size	A3 (297 x 420 mm)
Color	No
Character pitch	10 cpi
Maximum resolution	240 x 144 DPI
Maximum printing width (columns)	136
Print technology	Dot matrix
Dimensions (WxDxH)	589 x 360 x 157 mm
Standard interfaces	Parallel, USB 1.1
Optional connectivity	Ethernet
Country of origin	Indonesia
Sound pressure level (printing)	55 dB
Mean time between failures (MTBF)	20000 h
Sustainability certificates	ENERGY STAR
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Power consumption (typical)	53 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 80 %
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	2040 mm
Quantity per pallet	14 pc(s)
Quantity per pallet (UK)	21 pc(s)
Quantity per pallet layer	2 pc(s)
Quantity per pallet layer (UK)	3 pc(s)
Package depth	700 mm
Package width	460 mm
Package height	270 mm
Package weight	11740 g
Quantity per pack	1 pc(s)
