EPSON FX-890/2190 Revision B
Troubleshooting Troubleshooting Based on Symptoms 57
3.2.4 Abnormal paper feeding
Table 3-6. Abnormal paper feeding
Step Action and Question Yes No
Parts below can be the source of this error (Chapter 4 Disassembly and Assembly)
Front PE (Paper End) Detector (p.87)
Harness of Front PE Detector
Rear PE Detector (p.87)
Harness of Rear PE Detector
Release Detector (p.86)
Harness of Release Detector
Rear Paper Guide Assembly (p.90)
PF Motor (p.83)
PF Gear Train (p.84)
C524MAIN Board (p.74)
1
Checking for foreign matters
Make sure that there are no foreign matters in the
following areas.
•Paper path
PF Gear Train
Is the problem solved?
Problem
solved
Go to Step 2
2
Connection of sensor
Make sure that the following sensors are connected
properly:
Front PE Detector (CN6)
Rear PE Detector (CN7)
Release Detector (CN11)
Is the problem solved?
Problem
solved
Go to Step 3
3
Defective sensor
Replace the defective one of the following sensors
with a new one:
Front PE Detector (CN6)
Rear PE Detector (CN7)
Release Detector (CN11)
Is the problem solved?
Replace the
defective
sensors.
Go to Step 4
4
Harness of sensor
Replace the defective harness of the following
sensors with a new one:
Front PE Detector (CN6)
Rear PE Detector (CN7)
Release Detector (CN11)
Is the problem solved?
Replace the
defective
harness.
Go to Step 5
5
Paper changeover mechanism
Is the paper feeding direction switched when you
operate the release lever?
Go to Step 6
Check PF
Gear Train
(p.84)
6
Paper feed mechanism
With power turned off, check to see if you can feed
paper by turning the platen knob by hand.
Can paper be fed by turning the platen knob by
hand?
Go to Step 7
Check the
paper feed
mechanism
7
PF Motor
Replace the PF Motor with a new one.
Is the problem solved?
Replace the PF
Motor.
Go to Step 8
8
Main Board
Replace the Main Board with a new one.
Is the problem solved?
Replace the
Main Board.
Go to 3.2.11
Electrical
Noise (p.62)
