Epson FX-2190 Service Manual

EPSON FX-890/2190 Revision B
Appendix Parts List 126
FX-2190
Table 7-12. Parts List - FX-2190
Ref. No. Description
NON FIG "SOFTWARE CD-ROM,EAI"
NON FIG USER’S GUIDE
100 "HOUSING ASSY.,LOWER"
101 FOOT
102 "HOUSING ASSY.,UPPER"
103 "COVER ASSY.,PRINTER,REAR"
104 "COVER ASSY.,PRINTER"
105 WIHG;EPAG
106 SHEET GUIDE ASSY
107 "COVER ASSY.,FRONT"
108 KNOB
109 "SHIELD,PLATE,UPPER"
110 SHIELD PLATE;B
111 SHIELD PLATE
112 GROUNDING PLATE
113 "SHEET,PANEL"
115 "COVER,CONNECTOR,UPPER;EPAG"
116 "MOUNT,HOUSING"
117 "GUIDE,I/F BOARD"
118 "HOLDER,SHEET GUIDE,L"
119 "HOLDER,SHEET GUIDE,R"
120 "LOGO PLATE,12X48;C"
121 "STOPPER,COVER,FRONT"
122 "HOLDER,CABLE"
123 FAN ASSY.
125 C.B.S. SCREW(B300204211)
126 "C.B.P-TITE SCREW,3X12,F/ZN"
127 C.B.S. SCREW(B300204211)
132 "GROUNDING PLATE,I/F"
133 "GROUNDING PLATE,I/F,UPPER"
135 "C.B.S-TITE,3X20,F/ZN"
150 "DETECTOR ASSY.,CASE OPEN"
151 "HOLDER,DETECTOR"
(CN2) "GROUNDING PLATE,I/F"
200 "BOARD ASSY., MAIN"
330 "BOARD ASSY., POWER SUPPLY"
372 HARNESS
373 HARNESS
400 UL/CSA APPROVED P.S. CORD SET 10A 125V
450 "HOUSING ASSY.,PANEL"
B1 BEADS CORE
B2 BEADS CORE
B29 BEADS CORE
CN1 CONNECTOR 57RE-40360-830B(D7B)
CN11 CONNECTOR
CN12 CONNECTOR
CN13 CONNECTOR
CN14 CONNECTOR
CN15 CONNECTOR
Table 7-12. Parts List - FX-2190
Ref. No. Description

Epson FX-2190 Specifications

General

Maximum print size	A3 (297 x 420 mm)
Color	No
Character pitch	10 cpi
Maximum resolution	240 x 144 DPI
Maximum printing width (columns)	136
Print technology	Dot matrix
Dimensions (WxDxH)	589 x 360 x 157 mm
Standard interfaces	Parallel, USB 1.1
Optional connectivity	Ethernet
Country of origin	Indonesia
Sound pressure level (printing)	55 dB
Mean time between failures (MTBF)	20000 h
Sustainability certificates	ENERGY STAR
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Power consumption (typical)	53 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 80 %
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	2040 mm
Quantity per pallet	14 pc(s)
Quantity per pallet (UK)	21 pc(s)
Quantity per pallet layer	2 pc(s)
Quantity per pallet layer (UK)	3 pc(s)
Package depth	700 mm
Package width	460 mm
Package height	270 mm
Package weight	11740 g
Quantity per pack	1 pc(s)
