Epson LX-300+II RTP User Manual

EPSON LX-300+II/300+II RTP/1170II Revision D
Appendix Parts List 119

Parts List for LX-1170II
581 C.B.S-TITE SCREW,3X4,F/ZN-3C
590 LEVER,RELEASE
650 PRINTHEAD,D3910-1
651 LABEL,WARNING
652 ROLLER,PAPER EJECT;B
653 COVER,BOTTOM,CR
654 TRACTOR ASSY.
Table A-14. LX-300+II Parts List
Code Part Name
Table A-15. LX-1170II Parts List
Code Part Name
100 HOUSING ASSY, LOWER
103 HOUSING,UPPER
104 SHIELDPLATE,LOWER
105 COVER ASSY.,PRINTER
106 KNOB
107 COVER ASSY.,PRINTER,REAR
109 SHEET GUIDE ASSY.
111 SHIELDPLATE,UPPER
116 HEXAGON NUT
117 GROUNDINGPLATE
118 GROUNDING PLATE,PANEL
119 C.B.P-TITE SCREW,3X10,F/ZN-3C
120 LOGO PLATE
121 GROUNDING PLATE,L
122 GROUNDING PLATE,R
123 FERRITE CORE,FPC-25-20
124 SHEET,PROTECT,L
125 CONNECTOR LOCK NUT
126 SHEET,PROTECT,R
128 C.B.S-TITE SCREW,3X4,F/ZN-3C
129 C.B.B-TITE(W(13)) SCREW,3X14,F/ZN-3C
130 C.B.(O) SCREW 4X8 F/ZG-3C
180 GUIDE,STACKER
200 BOARD ASSY.,MAIN
