Epson LX-300+II RTP User Manual

EPSON LX-300+II/300+II RTP/1170II Revision D
Appendix Parts List 120
300 BOARD ASSY.,POWER SUPPLY
320 HARNESS
400 POWER CABLE
401 HARNESS
450 BOARD ASSY.,PANEL
451 SHEET,PANEL;D
500 PRINTER MECHANISM(ASP),M-3N60-100
501 FRAME ASSY.,LEFT
502 FRAME,RIGHT
503 MOTOR ASSY.,CR
504 EXTENSION SPRING,8.10
505 LEVER ASSY.,PLANET
506 SHAFT,CR,GUIDE
508 GROUNDING PLATE,PAPER GUIDE,UPPER
509 SPURGEAR,13.2
510 COMBINATIONGEAR,5.1,16.2
511 MOTOR ASSY.,PF
512 COVER,RD
513 RATCHET,RD
514 DETECTOR,LEAF,B2
515 GROUNDING WIRE,PLATEN
516 PULLEY ASSY.,DRIVEN
517 HARNESS,HP
518 C.P.B-TITE SCREW,3X14,F/ZN-3C
519 ROLLER,PAPER EJECT
Table A-15. LX-1170II Parts List
Code Part Name
520 PAPER GUIDE
521 DETECTOR,PE,REAR
522 HARNESS,PE,REAR
523 DETECTOR,PE,BOTTOM
524 HARNESS,PE,BOTTOM
525 HOLDER,ROLLER,PF
526 ROLLER,PF,DRIVEN
527 ROLLER,PF,DRIVEN,REAR;C
528 COMPRESSION SPRING,13.72
529 SHAFT,RELEASE
530 PAPER GUIDE ASSY.
531 E-RING,8,F/UC-3C
532 BUSHING,11
533 U-TYPE,11.2X0.13X16S/NA
534 PLAIN WASHER
535 PLATEN
536 CARRIAGE SUB ASSY.
537 GROUNDING PLATE,HEAD
538 OIL PAD
539 LEVER,G,ADJUST
540 RIBBON MASK
541 TIMING BELT
542 BUSHING,PARALLEL,ADJUST
543 CABLE,HEAD
544 HARNESS,PG
Table A-15. LX-1170II Parts List
Code Part Name
