REV.-A
3. Unlock the two levers securing the
printhead to the carriage by pulling them down. Then lift and :-.
f
~~
remove the printhead.
Figure 4-2. Printhead Removal
4.
Disconnect the head cable from the connector on the printhead.
NOTE
● For the European version of the printer, a net is mounted on the printhead.
Figure 4-3. Net
p
-. ,..,
4-4
