REV.-A
3.2.3 Cut Sheet Feeder Disassembly and Reassembly
This section describes the procedure for removing the hopper unit of the C806 12’ cut sheet feeder.
Unless otherwise specified, reassembly
is
performed by reversing the sequence. The diagrams in Figure
A-2 1, which are provided as reference for disassembly and reassembly, show an exploded view of the
parts configuration.
The required tools are listed in Table 3-6.
Table 3-6. Tools for Assembly or Disassembly
Designation
Availability
Part No.
Philips screwdriver No.2
o
B743800200
E-ring holder #6
o
B740800800
o: Commercially available
CAUTION
For safety, gloves should be worn during disassembly and assembly.
Dismount the cut sheet feeder from the printer before starting disassembly.
Do not allow oil or grease to contaminate the paper path. If contamination does occur, wipe it away
with alcohol.
WARNING
If it is necessary to replace one of the paper loading rollers, both right and left rollers must be replaced
at the same time.
f.
.:
.*.
-.
;
---
ā€˜. . . .
.
3-1o
