Epson LX-810 Technical Manual

REV.-A
Printhead
#7x5 COM. x19#18
I t
o #l
o #2
o #3
o #4
o #5
O ~6
o #7
O .8
0 #9
( Wire assignment)
Coil Resistance:
19.2 A 1.9 Q at 25°C
(8etween each dot wire and common.)
#“ 1 # 3 #2#4#6
( Terminal assignment)
Figure 5-1. Printhead Resistance
5-6

Epson LX-810 Specifications

General

Print Method	Impact dot matrix
Number of Pins	9
Character Sets	96 characters (USASCII)
Line Spacing	1/6 inch
Paper Path	Rear
Interface	Centronics parallel
Noise Level	55 dB (A)
