Epson LX-810 Technical Manual

REV.-A
5.3 UNIT REPAIR
This section indicates the points to be checked in response to problems, and the measures to be taken
based on the result of the check. Utilize the checkpoints to determine and correct defective components.
Tables 5-4 and 5-5, below, are divided into the five following columns:
● Problem:
Indicates the problem
● Symptom:
Indicates potential condition which may be underlying the problem. You must check
to see which if any of the symptoms apply.
‘ Cause:
Indicates the potential cause of the problem.
● Checkpoint:
Perform this check to determine whether the problem is the result
of the cause listed
at left.
● Solution:
Indicates the repair that will correct the fault.
t
------
5-10

Epson LX-810 Specifications

General

Print Method	Impact dot matrix
Number of Pins	9
Character Sets	96 characters (USASCII)
Line Spacing	1/6 inch
Paper Path	Rear
Interface	Centronics parallel
Noise Level	55 dB (A)
