Friction/Tractor Sensor
:$-2!
+.
The release sensor senses the position of the release lever in order to detect whether tractor feed or
friction feed is in effect.
Release Lever Position : Front + F:riction Feed + OFF + HIGH level
Release Lever Position : Rear -+ Tractor Feed ~ ON ~ LOW level
Front
\
?“’”-
\ i,
\
Rear
/
ease Lever
~
~. w
<
Friction/Tractor Sensor
Figure 2-7’. Release Sensor Mechanism
+5V
4
oJKL-=
r’
R95
IK
Figure
:2-8. Release Sensor Circuit
