Maintenance and Transportation 77
3. Use the screwdriver included with the replacement lamp or a
#2 Phillips-head screwdriver to loosen the screw holding the lamp
cover (the lamp cover is located on top of the projector).
4. Slide the cover out, then lift it off.
5. Use the screwdriver to loosen the two screws holding the lamp in
place. (You can’t remove the screws.)
6. Hold the lamp as shown and pull it straight out.
note
The lamp(s) in this
product contain mercury.
Please consult your state and
local regulations regarding
disposal or recycling. Do not
put in the trash.
Don’t remove
these screws
To Next Page
