Epson RC700-A Original Instructions

Functions 13. I/O Connector
RC700 Series Rev.3 149
13.2.1 Typical Output Circuit Application 1: Sink Type (NPN)
L
L
10 output No.0
I/O-1
(same)
same
+DC
29 output No.8
30 output No.9
11 output No.1
12 output No.2
13 output No.3
14 output No.4
15 output No.5
27 output No.6
28 output No.7
17 output No.0～7 common (GND)
Load
GND
33 output No.8～15 common(GND)
13.2.2 Typical Output Circuit Application 2: Source Type (PNP)
L
L
10 output No.0
I/O-2
(same)
same
+DC
29 output No.8
30 output No.9
11 output No.1
12 output No.2
13 output No.3
14 output No.4
15 output No.
5
27 output No.6
28 output No.
7
17 output No.0～7 common (+DC)
Load
GND
33 output No.8～15 common(+DC)
