Functions 16. Option Slots
186 RC700 Series Rev.3
16.6.4 Input Circuit (Analog I/O Board)
Input resolution : 16 bit
I
nput range : voltage input: 0 to 5.12V, 0 to 10.24V, ±5.12V, ±10.24V
current input: 0 to 24mA
Input impedance (Voltage/Current)
: Applox.100k/Applox.422
Absolute rated voltage of input pins
: ±11V
Insulation specification : insulation between channels, bus insulation
16.6.5 Output Circuit (Analog I/O Board)
Output resolution : 16 bit
O
utput range : voltage output: 0 to 5V, 0 to 10V, ±5V, ±10V
current output: 0 to 20mA, 4 to 20mA
Output impedance (Voltage/Current)
: Applox.17/Applox.50M
Absolute rated voltage of output pins
: ±11V
Load resistance/capacity (@voltage output)
: 1k or more/5nF or less
Load resistance /inductance (@voltage output)
: 300k or more/50mH or less
Insulation specification : insulation between channels, bus insulation
CAUTION
Analog input/output may not function properly if performing improper wiring or
configuration.
Operating under external noise may affect to the analog input/output. Make
sure the noise environment such as weather the cable is shielded.
Use the shield/twist cable.
Never apply a voltage or current which is out of input/output range to the analog
input/output pin. Applying a voltage more than ±11V may result in malfunction
of the board.
Improper wiring or short circuit may cause malfunction of the parts on the board
and then improper function of the robot system.
