Epson RC700-A Original Instructions

Functions 14. I/O Remote Settings
RC700 Series Rev.3 155
(*9) This function changes the output condition of MotorsOn, AtHome, PowerHigh, and MCalReqd.
By setting this signal with the condition selected using SelRobot1 - SelRobot16, you can switch the output
condition.
Once you select the condition, it will be kept until you change it or turn OFF / restart the Controller.
All Manipulators are selected as default.
(*10) The values specified by “SelAlarm1, 2, 4, and 8” correspond to the alarm numbers.
Alarm #
Target
SelAlarm1
SelAlarm2
SelAlarm4
SelAlarm8
1
Controller battery
1
0
0
0
2
Battery of the robot connected to CU
0
1
0
0
3
Grease of the robot connected to CU
1
1
0
0
4
Battery of the robot connected to DU1
0
0
1
0
5
Grease of the robot connected to DU1
1
0
1
0
6
Battery of the robot connected to DU2
0
1
1
0
7
Grease of the robot connected to DU2
1
1
1
0
8
Battery of the robot connected to DU3
0
0
0
1
9
Grease of the robot connected to DU3
1
0
0
1
0=OFF, 1=ON
The following parts are subject to grease up.
6-axis robot: Bevel gear on the Joint #6
SCARA, RS series: Ball screw spline unit on the Joint # 3
(*11) The specified alarm can be canceled by selecting the conditions using SelAlarm1-SelAlarm8 and setting
this signal.
(*12) Operation of all tasks and commands, power mode of the robot, and PowerHigh command are executed by
the setting value of the controller preferences.
Preferences (1): “Motor power low when ForcePowerLow signal OFF”
Preferences (2): “ForcePowerLow signal change pauses all tasks”
For details of the Controller preferences, refer to EPSON RC+ 7.0 User’s Guide
[Setup]-[System Configuration]-[Controller]-[Preferences] in 5.12.2 [System Configuration]
Command (Setup Menu).
Preferences (1) Preferences (2) ForcePowerLow
All tasks and
commands
Power mode PowerHigh
0
0
1→0
Stop
Low only
Accept
0
0
0→1
Stop
Low only
Not accept
0
1
1→0
Continue
High/Low
Accept
0
1
0→1
Temp. stop
Low only
Not accept
1
0
1→0
Stop
Low only
Not accept
1
0
0→1
Stop
Low only
Accept
1
1
1→0
Temp. stop
Low only
Not accept
1
1
0→1
Continue
High/Low
Accept
