F
Leave a 10 to 20 cm (3.94 to 7.87 inches) wide
section in the center of the media, and cut at
least 25 cm (9.84 inches) in height from the left
and right corners of the media.
Cutting the media prevents feeding problems,
such as the left and right corners of media
being folded and caught at the start of take-up.
For the subsequent steps, see the following depending
on how the media is rolled.
For information on taking-up with printed side out,
see U “Take-up with the Printed Side Facing Out”
on page 57.
For information on taking-up with printed side in, see
U “Take-up with the Printed Side Facing In” on
page 59.
Take-up with the Printed Side
Facing Out
A
While pulling the center section of the media
straight down, affix the media to the take up
roll core with commercially available adhesive
tape.
c
Important:
Attach the media to the take up roll core
with the media in a taut state. If media is
attached in a loose state, the media may
move around during take-up.
B
Press the button on the control panel to
feed enough media for a single wrap around the
roll core.
SC-R5000 Series/SC-R5000L Series User's Guide
Basic Operations
57
