Supported Media
The following media can be used with the printer.
Print quality is greatly affected by the type and quality
of media used. Choose a media suited to the task at
hand. For information on use, refer to the
documentation supplied with the media or contact the
manufacturer. Before buying media in large
quantities, try printing on a smaller sample and check
the results.
c
Important:
Do not use media that is wrinkled, scuffed, torn,
or dirty.
Roll media
Roll core size 2 or 3 inch
Roll outer diameter Media Feeding Unit: Up to 250
mm (9.8 in.)
Auto take-up reel unit: Up to 200
mm (7.87 in.)
Media width 300 to 1,626 mm (64 inches)
Media thickness Maximum 1 mm (0.039 inches)
Roll weight Maximum 45 kg (99 lbs)
Moving and Transporting
the Printer
This section describes how to move and transport the
product.
Moving the Printer
This section assumes that the product is being moved
to another location on the same floor without
traversing stairs, ramps, or lifts. See below for
information on moving the printer between floors or
to another building.
U “Transport” on page 136
Caution:
Do not tilt the product more than 10 degrees
forward or back while moving it. Failure to
observe this precaution could result in the printer
falling over, causing accidents.
c
Important:
❏ Do not remove the ink supply units. Failure to
observe this precaution could cause the print
head nozzles to dry out.
❏ Be sure to move the printer under the
following conditions.
❏ Do not separate the ink unit and the
printer. (Transport the printer with the
ink tube connector connected to the back
of the printer and the connector locked.)
❏ Make sure the ink unit wire is fastened.
Getting Ready
A
Confirm that the printer is off.
B
Remove the Waste Ink Bottle.
U “Replacing the Waste Ink Bottle” on
page 90
SC-R5000 Series/SC-R5000L Series User's Guide
Appendix
133
