Epson Stylus CX7300 Service Manual

EPSON Stylus CX7300/CX7400/DX7400/NX200/TX200 series/SX200 series/Stylus CX8300/CX8400/DX8400/NX400/TX400 series/SX400 series Revision C
PRODUCT DESCRIPTION Printing Specifications 10
Confidential
1.2 Printing Specifications
1.2.1 Basic Specifications
1.2.2 Ink Cartridge
The product numbers of the EPSON ink cartridges for this printer are shown below.
Note *1 : Available only with CX8300/TX400 series.
*2 : Available only with CX7300/TX200/TX400 series.
*3 : Available only with CX7300/CX8300 series.
*4 : Available only with TX200/TX400 series.
 Shelf life
Two years from production date (if unopened), six months after opening package.
 Storage Temperature
 Dimension
12.7 mm (W) x 68 mm (D) x 47 mm (H)
Table 1-1. Printer Specifications
Item Specification
Print method On-demand ink jet
Nozzle configuration
Black: 90 nozzles x 1
Color: 90 nozzles x 3 (Cyan, Magenta, Yellow)
Print direction Bi-directional minimum distance printing, Unidirectional printing
Print resolution
Horizontal x Vertical (dpi)
• 360 x 120 • 1440 x 720
• 360 x 360 • 1440 x 1440
• 360 x 720 • SMGA 5760 x 1440 (2880 x 1440)
• 720 x 720
Control code
• ESC/P Raster command
• ESC/P-R (RGB) command
• EPSON Remote command
Input buffer size 64 Kbytes
Paper feed method Friction feed, using the ASF (Auto Sheet Feeder)
Paper path Top feed, front out
Paper feed rates T.B.D. mm/sec (at 25.4 mm feed)
PF interval Programmable in 0.01764 mm (1/1440 inch) steps
Table 1-2. Product No. of Ink Cartridges
Color EAI Latin Euro CISMEA Asia
Black
T0681 (S)*
1
T0691 (2S)
T0881 (3S)*
2
T0881 (3S)*
4
T0731H (S)
T0731HN (S)*
4
T0731 (2S)
T0731N (2S)*
4
T0901 (3S)*
3
T0711H (S)
T0711 (2S)
T0891 (3S)*
4
T0731H (S)
T0731HN (S)*
4
T0731 (2S)
T0731N (2S)*
4
T0731HN (S)*
4
T0731 (2S)
T0731N (2S)*
4
Cyan
T0692 (3S)
T0692 (3S)*
4
T0882 (4S) *
2
T0882 (4S) *
4
T0732 (3S)
T0732N (3S)*
4
T0712 (3S)
T0712 (3S)*
4
T0892 (4S)*
4
T0732 (3S)
T0732N (3S)*
4
T0732 (3S)
T0732N (3S)*
4
Magenta
T0693 (3S)
T0693 (3S)*
4
T0883 (4S) *
2
T0883 (4S) *
4
T0733 (3S)
T0733N (3S)*
4
T0713 (3S)
T0713 (3S)*
4
T0893 (4S)*
4
T0733 (3S)
T0733N (3S)*
4
T0733 (3S)
T0733N (3S)*
4
Yellow
T0694 (3S)
T0694 (3S)*
4
T0884 (4S) *
2
T0884 (4S) *
4
T0734 (3S)
T0734N (3S)*
4
T0714 (3S)
T0714 (3S)*
4
T0894 (4S)*
4
T0734 (3S)
T0734N (3S)*
4
T0734 (3S)
T0734N (3S)*
4
Table 1-3. Storage Temperature
Situation Storage Temperature Limit
When stored in individual boxes
-20
o
C to 40
o
C
(-4
o
F to 104
o
F)
1 month max. at 40
o
C (104
o
F)
When installed in main unit
-20
o
C to 40
o
C
(-4
o
F to 104
o
F)
C A U T I O N
 Do not use expired ink cartridges.
 The ink in the ink cartridge freezes at -16 °C (3.2
o
F). It takes
about three hours under 25 °C (77
o
F) until the ink thaws and
becomes usable.

Epson Stylus CX7300 Specifications

General

Device Type	Multifunction printer
Printer Type	Inkjet
Maximum Print Resolution	5760 x 1440 dpi
Scanner Type	Flatbed
Scanning Resolution	1200 x 2400 dpi
Interface	USB 2.0
Ink Cartridge Configuration	4 individual ink cartridges
Inkjet Technology	Epson Micro Piezo
Display	LCD
Media Type	Plain paper, photo paper
Standard Media Size	A4
Paper Sizes Supported	A4, A5, B5, Legal, Letter
Dimensions (W x D x H)	43.4 cm x 32.7 cm x 18.5 cm
Weight	5.9 kg
