1.5.2 Memory Card Slots
Note: • Memory Stick/PRO, SD/MMC and xD-Picture Card shares the same slot.
• When cards are inserted in the two slots at once, the slot which will be accessed first is determined according to the priority shown in the table.
• To select a card that has been inserted in a non-active slot, first remove the card in the active slot.
• In memory card direct printing mode, the image files in the active slot are valid and have assigned frame numbers. The number of images will not change if a card is inserted in another
nonselected slot.
• When the card inserted in the slot is accessed from the PC, only one drive is displayed at a time as a removable disk* and only the card that is in the active slot can be accessed via the
removable disk. A card that has been inserted into a non-selected slot cannot be accessed.
(This is for Windows. For Macintosh, the card in the active slot will be mounted on the desktop.)
• Does not support 5V type of memory cards.
• When a memory card is being accessed, do not touch the memory card.
• For detailed information on the supported file system and formatting the memory card, refer to “ 1.7.2 Memory Card Direct Print Function ( p. 31 ) ”.
C A U T I O N
In the case of TX200/TX400 series; if you insert a Memory Stick
DUO to the Memory Card Slot without using the adapter, make
sure to turn off the printer first, then remove the card using
tweezers.
Table 1-15. List of Supported Memory Card
Priority Slot Compatible memory card Standard Max. capacity Remarks
1
Memory Stick/
Memory Stick
PRO
Memory Stick “MemoryStick Standard” Format Specification Ver.1.42-00 compatible 128MB Includes versions with memory select function
MagicGate Memory Stick 128MB Copy protection function is not supported
MagicGate Memory Stick Duo An adapter should be used
Memory Stick PRO Memory Stick PRO Format Specifications-without security specifications Ver.1.02-00
compatible
4GB
Copy protection function is not supported
Memory Stick Duo MemoryStick Duo Format Specification Ver.1.11-00 compatible The Memory Stick Duo adapter should be
used
Memory Stick Pro Duo MemoryStick PRO Duo Format Specification Ver.1.02-00 compatible The Memory Stick Duo adapter should be
used.
Memory Stick micro Memory Stick Micro Format Specification Ver.1.02-00 compatible The Memory Stick adapter for standard size
should be used.
SD/MMC SD (Security Digital) SD Memory Card Specifications / PART1. Physical Layer Specification Ver. 2.0 compatible
2GB
miniSD/microSD The SD adapter should be used
SDHC
8GB
Speed Class is not supported
miniSDHC/microSDHC The SD adapter should be used
Speed Class is not supported
MultiMediaCard
MultiMediaCard Plus
MultiMediaCard Standard Ver. 4.1 compatible
64MB/4GB
Only MultiMediaCard Plus supports 4GB
xD-Picture card xD-Picture card xD-Picture Card Specification Ver.1.20 compatible 2GB Type M/H supported
2
CF Type II Compact Flash CF+ and CompactFlash Specification Revision 3.0 compatible (CX7300/CX8300 series) 4GB True-IDE compatible memory card only
CF+ and CompactFlash Specification Revision 4.1 compatible (TX200/TX400 series) 32GB
Microdrive

Epson Stylus CX7300 Specifications

General

Device Type	Multifunction printer
Printer Type	Inkjet
Maximum Print Resolution	5760 x 1440 dpi
Scanner Type	Flatbed
Scanning Resolution	1200 x 2400 dpi
Interface	USB 2.0
Ink Cartridge Configuration	4 individual ink cartridges
Inkjet Technology	Epson Micro Piezo
Display	LCD
Media Type	Plain paper, photo paper
Standard Media Size	A4
Paper Sizes Supported	A4, A5, B5, Legal, Letter
Dimensions (W x D x H)	43.4 cm x 32.7 cm x 18.5 cm
Weight	5.9 kg
