Epson STYLUS PRO 4910 - 1.2 Basic Specifications

Epson Stylus Pro 4900/Epson Stylus Pro 4910 Revision A
PRODUCT DESCRIPTION Basic Specifications 13
Confidential
1.2 Basic Specifications
1.2.1 Basic Specifications
1.2.2 Electric Specifications
Item Specification
Print method On-demand inkjet
Nozzle configuration
Black system:
360 nozzles x three colors
(Photo Black, Matte Black, Light Black, Light Light Black)
Color system:
360 nozzles x seven colors
(Green, Yellow, Orange, Cyan, Light Cyan, Vivid Magenta, Vivid
Light Magenta)
Maximum resolution 2,880dpi x 1,440dpi
Control code ESC/P2 (command is nondisclosure)
Paper feed method Friction
RAM 256 MB for Main, 64 MB for Network
Interface
USB 2.0 High Speed
Ethernet 10Base-T/100Base-TX
Item
Specification
Main body
SpectroProofer is
installed
Rated voltage 100 to 240 VAC
Input voltage range 90 to 264 VAC
Rated current 0.4 A to 0.7 A
Rated frequency 50 to 60 Hz
Input frequency range 49.5 to 60.5 Hz
Power
consumption
Operating Approx. 52 W Approx. 55 W
Standby 20 W 25 W
Sleep mode Approx. 8.5 W or less Approx. 8.5 W or less
Power off Approx. 0.5 W or less Approx. 0.5 W or less
Insulation resistance
10 MΩ or more
(between AC line and chassis at 500 VDC)
Dielectric strength
1.0 kVrms AC for 1 min. or 1.2 kVrms AC for 1 sec.
(between AC line and chassis)
Leek current 0.25 mA or less
Compliance with regulations
Conforms to International Energy Star Program
(Category: the harmonic restraint measure guideline)
Conforms to VCCI Class B (with full options installed)
