Figure 4-84. Adjustment Pattern
Inspection Program Ver. : XXXXXXXX ,F/W version : XXXXXXXXXX
Head-ID : xx xx xx xx xx xx xx xx xx xx xx xx xx xx xx xx xx xx xx xx xx xx xx
USB-ID :XXXXXXXXXXXXXXXXXX RTC: XX XX XX XX XX XX , XX : XX
M/C No. : xxxxxxxxxxxxxxxxx ,
PF Adjustment
Input Value = -12 Adjusted Value = -12 (99783)
-8 (-7) -6 (-5) -4 (-3) -2 (-1) 0 (1) 2 (3) 4 (5) 6 (7) 8
