122
Advanced Media Setting menu (in the Roll Paper menu)
Setting Options Description
Platen Gap 1.6
2.1
Adjusts the distance between the print head
and the paper; displayed when Custom
Paper is selected as the Paper Type setting
Top/Bottom Margins Standard
Top 3 mm/Bottom 3
mm
Top 15 mm/Bottom 15
mm
Top 45 mm/Bottom 15
mm
The Standard margins are as follows for the
top and bottom:
• CAD/line drawings: 3 mm
• Other: 30 mm
Select a different value as necessary.
Note: Left and right margins are always 3
mm.
Back Tension Auto
Standard
High
Extra High
Select High or Extra High if paper wrinkles
during printing
Drying Time Drying Time per Pass Select from 0 to 10 seconds for the amount of
time the print head pauses to allow drying
after each pass
Drying Time per Page Select from 0 to 60 minutes for the amount of
time the printer pauses to allow drying after
each page is printed
Auto Cut On
Off
Select On to automatically cut roll paper after
each page is printed, or select Off to cut paper
manually
Auto Sheet Feeder menu
Setting Options Description
Media Adjust Start Prints an adjustment pattern to check and
adjust print quality or custom paper settings;
follow the on-screen instructions
To Next Page
