1 Maintenance box cover

2 Maintenance box

3 AC inlet

4 Ethernet LAN port

5 Status light

6 Data light

7 OPTION port (for scanner connection)

8 USB port

9 Airflow vents

Caution: Do not block the airflow vents shown above.

Parent topic: Printer Part Locations

Control Panel Parts

home button

power light

power button

4 LCD touchscreen
