176
•Recommended value for setting the barcode/2D symbol font (2D symbol of matrix type)
- : Not supported.
*
1 : Whether paper feed is performed during printing 2D symbol can be checked in [Display
Media Feed Position] - [Display Print Preview] in the Print Preview function. For this
function, see "Print Preview" on page 181.
*2: Only QRCode is confirmed.
3
Click [Add].
The selected 2D symbol font is saved and the font name is added to the font list.
Symbol Category
Print
Quality
Print Status
(*1)
Minimum Cell Size
[by 360 dpi]
ANSI
Grade
D or
higher
ANSI
Grade
C or
higher
ANSI
Grade
B or
higher
AztecCode
QRCode
Plain
Media,
Plain Media
Label
Speed
No Paper feed 6 dot - -
With Paper feed 8 dot - -
Quality
No Paper feed 6 dot - -
With Paper feed 8 dot - -
Fine Media,
Fine Media
Label,
Synthetic
Media
Label,
PET Film,
Wrist Band
Speed
No Paper feed 5 dot 6 dot (*2)
With Paper feed 6 dot 7 dot -
Quality
No Paper feed 5 dot 6 dot (*2)
With Paper feed 6 dot 7 dot -
• The 2D symbol font can be registered up to 30.
• The 2D symbol font setting can be overwritten by clicking [Save] after selecting the font
name from the font list and changing the setting.
• The 2D symbol font setting can be deleted by clicking [Delete] after selecting the font
name from the font list.
• Test print is executed according to the setting by clicking [Print] after inputting the text in
the box.
