Epson TM-T81

Confidential
EPSON
TITLE
SHEET
REVISION
NO
SHEETNEXT
89 90
A
TM-T81
Specification
(STANDARD)
GS ( k pL pH cn fn [parameters]
[Name] Set up and print symbol
[Description] • Processes the data for two-dimensional codes.
• pL, pH specify (pL + pH × 256) as the number of bytes after pH (cn, fn, and
[parameters]).
• cn specifies the type of symbology.
• fn specifies the function.
• [parameters] specify the process of each function.
cn Type of Symbology
48 PDF417
49 QR Code
cn fn
Format
Function
No.
Function name
65
GS ( k p
L pH cn fn n
065 PDF417: Set the number of columns in
the data region.
66
GS ( k p
L pH cn fn n
066 PDF417: Set the number of rows.
67
GS ( k p
L pH cn fn n
067 PDF417: Set the width of the module.
68
GS ( k p
L pH cn fn n
068 PDF417: Set the row height.
69
GS ( k p
L pH cn fn m n
069 PDF417: Set the error correction level.
70
GS ( k p
L pH cn fn m
070 PDF417: Select the options.
80
GS ( k p
L pH cn fn m
d1...dk
080 PDF417: Store the data in the symbol
storage area.
81
GS ( k p
L pH cn fn m
081 PDF417: Print the symbol data in the
symbol storage area.
48
82
GS ( k pL pH cn fn m
082 PDF417: Transmit the size information of
the symbol data in the symbol storage
area.
65
GS ( k p
L pH cn fn n1 n2
165 QR Code: Select the model.
67
GS ( k p
L pH cn fn n
167 QR Code: Set the size of module.
69
GS ( k p
L pH cn fn n
169 QR Code: Select the error correction
level.
80
GS ( k pL pH cn fn m
d1...dk
180 QR Code: Store the data in the symbol
storage area.
81
GS ( k p
L pH cn fn m
181 QR Code: Print the symbol data in the
symbol storage area.
49
82
GS ( k p
L pH cn fn m
182 QR Code: Transmit the size information
of the symbol data in the symbol storage
area.
• "Symbol data" refers to the data received with <Function 080 or 180> before
encoding.
• "Symbol storage area" refers to the range for storing data received with <Function
080 or 180> before encoding.
