Rev. B Disassembly and Assembly 4-11
TM-U220 Type A Service Manual
Confidential
DIsassembly Procedures
Reassembly
steps Part names Assembly procedures
Platen release lever
(504)
Remove 2 E-rings 3 (E01), and remove the platen release lever
(504) and platen shaft (1054).
6 Lubricate the platen shaft (1054) with G-15.
Gear plate D sub
assembly (1057)
Paper feed middle gear
(509)
Paper feed middle gear
B (510)
Remove 2 screws (S10), and remove the gear plate D sub
assembly (1057).
Remove 1 E-ring 3 (E01), and remove the paper feed reduction
gear 2 (1058).
Remove the paper feed middle gear (509) and paper feed
middle gear B (510).
6 Lubricate the gear plate D sub assembly (1057) with G-15.
Platen assembly 3 (522) Remove 1 E-ring 3 (E01), and pull out the platen shaft (1054).
In doing so, remove the paper feed middle gear B (510), the
platen release plate (1055), and the platen release lever (504)
together. Take care not to lose the platen release spring
(1056).
Remove platen assembly 3 (522).
Remove 1 screw (S09), and remove the bottom holding plate
BM (1061).
When installing the frame rotation unit (1005) on the base
frame assembly, check how to lead the autocutter unit (113)
cable. (See page 4-19.)
Platen frame (1053) Remove 3 screws (S10), and remove the platen frame (1053).
Platen rotation frame 2
(1125)
After this, you can remove the platen rotation frame 2 (1125).
6 Lubricate the platen rotation frame 2 (1125) with G-15.
