4.4.11 Foot
1. Remove the Printer Mechanism. (Refer to 4.4.4 Lower Housing / Printer
Mechanism (p.86).)
2. Remove the six foot at the backside of the Lower Housing.
Figure 4-105. Removing the Foot
A D J U S T M E N T
R E Q U I R E D
After replacing or removing the Waste Ink Pads and the Waste Ink
Tray Assy, always make the required adjustments referring to the
following.
 “Chapter 5 Adjustment (p.128)”
