WorkForce 1100/Epson Stylus Office T1110/B1100/T1100/Epson ME Office 1100 Revision C
Product Description Interface 16
Confidential
1.2.5 Printing Area
The printing area for this printer is shown below.
Note * : The margins for Borderless print are margins that bleed off the edges of paper.
Figure 1-2. Printing Area
1.3 Interface
This printer is equipped with the USB device port on the rear of the printer for
connecting with a host such as a computer. The following is the specifications of the
port.
Specification:
Universal Serial Bus Specifications Revision 2.0
Universal Serial Bus Device Class Definition for Printing Devices Version
1.1
Transfer rate: 480 Mbps (High Speed Device)
Data format: NRZI
Compatible connector: USB Series B
Max. cable length: 2 [m] or less
The “Model Name” is replaced as shown in the following table.
Table 1-7. Printing Area (Margins)
Print Mode Paper Size
Margin*
Left Right Top Bottom
Standard print Any size 3 mm 3 mm 3 mm 3 mm
Envelopes 5 mm 5 mm 5 mm 20 mm
Borderless
print
A4/Letter to 5” x 7”/
16:9 wide
2.54 mm 2.54 mm 2.96 mm 4.02 mm
4” x 6” 2.54 mm 2.54 mm 1.34 mm 2.54 mm
Table 1-8. Device ID
When IEEE 1284.4 is Enabled When IEEE 1284.4 is Disabled
@EJL<SP>ID<CR><LF>
MFG:EPSON;
CMD:ESCPL2,BDC,D4,D4PX;
MDL:
Model Name
;
CLS:PRINTER;
DES:EPSON<SP>
Model Name
;
CID:EpsonStd5;
@EJL<SP>ID<CR><LF>
MFG:EPSON;
CMD:ESCPL2,BDC;
MDL:
Model Name
;
CLS:PRINTER;
DES:EPSON<SP>
Model Name
;
CID:EpsonStd5;
Destination Model Name
North America
WorkForce 1100
Latin America
Epson Stylus Office T1110
Euro
Epson Stylus Office B1100
Asia/CISMEA
Epson Stylus Office T1100
China
Epson ME OFFICE 1100
