SECTION 2 SYSTEM: INTRODUCTION
2.01 How To Use This Manual
This Owner’s Manual applies to just product(s) listed on page i.
To ensure safe operation, read the entire manual, including the chapter on safety instructions and
warnings.
Additional copies of this manual may be purchased by contacting ESAB at the address and phone
number in your area listed on back cover of this manual. Include the Operating Manual number and
equipment identication numbers.
Electronic copies of this manual can also be downloaded at no charge in Acrobat PDF format by go-
ing to the ESAB web site listed below and clicking on "Product Support" / "ESAB Documentation": /
"Download Library", then navigate to "Plasma Equipment" and then "Manual".
http://www.esab.com
2.02 Equipment Identication
The unit’s identication number (specication or part number), model, and serial number usually appear
on a data tag attached to the bottom. Equipment which does not have a data tag such as torch and
cable assemblies are identied only by the specication or part number printed on loosely attached
card or the shipping container. Record these numbers on the bottom of page i for future reference.
2.03 Receipt Of Equipment
When you receive the equipment, check it against the invoice to make sure it is complete and inspect
the equipment for possible damage due to shipping. If there is any damage, notify the carrier imme-
diately to le a claim. Furnish complete information concerning damage claims or shipping errors to
the location in your area listed on the back cover of this manual.
Include all equipment identication numbers as described above, along with a full description of the
parts in error.
CSA / UL
Included items:
• CutMaster 40 Power Supply
• SL60™ Torch and Leads
• Work Lead with Work Clamp
• Spare Parts Kit ( 2 Electrodes, 2 Stando
Tips, 1 Gouging Tip, 1 Shield Cap and
1 Shield cup)
• 50 Amp to 20 Amp Adapter
• 20 Amp to 15 Amp Adapter
• Operating Manual
• Quick Start Guide
CE
Included items:
• CutMaster 40 Power Supply
• SL60™ Torch and Leads
• Work Lead with Work Clamp
• Spare Parts Kit ( 2 Electrodes, 2 Stando
Tips, 1 Gouging Tip, 1 Shield Cap and
1 Shield cup)
• 1/4" NPT to female BSP Adapter.
• Operating Manual
• Quick Start Guide
Move the equipment to the installation site before un-boxing the unit. Use care to avoid damaging
the equipment when opening the box.
