ESAB Cutmaster 40 - Power Supply Specifications (CE); Input Wiring Specifications (CE)

CUTMASTER 40
INTRODUCTION 0-5570
18
2.06 Power Supply Specications CE
CM 40 240 VAC 1 Phase Power Supply Specications
Input Power 230 VAC, Single Phase, 50 Hz
1 Phase Input Power Cable CE
Power Supply includes 2.5M single phase 2.5mm² input
cable with Schuko plug
Output Current 15 - 40 Amps, Continuously Adjustable
Power Supply Gas Filtering Ability Particulates to 5 Microns
Inlet Pressure 90-125 PSI (6.2-8.6 bar / 620-862 Kpa)
2.06.01 Additional Power Supply Specications
CM 40 Power Supply Duty Cycle *
Ambient Air Temperature
Duty Cycle Ratings @ 40° C (104° F)
Operating Range 0° - 50° C
Rating
230 VAC Units
Duty Cycle* 35% 60% 100%
Current
40 Amps 30 Amps 20 Amps
DC Voltage
135 130 135
* NOTE: The duty cycle will be reduced if the primary input power (AC) is low or the output voltage (DC) is higher than
shown in this chart.
2.07 Input Wiring Specications CE
1 Phase Input Cable Wiring Requirements
1 Phase CutMaster 40 Power Supply Input Cable Wiring Requirements
Input voltage Freq Power Input Suggested Sizes
Volts Hz kVA I max I
1
e
Fuse
(amps)
Flexible Cord
(Min. AWG)
1 Phase
230 CE 50 6.0 26.1 15.5 50 2.5mm
Line Voltages with Suggested Circuit Protection and Wire Sizes
Based on National Electric Code and Canadian Electric Code
NOTE!
Refer to Local and National Codes or local authority having jurisdiction for proper wiring requirements.
Cable size is de-rated based on the Duty Cycle of the equipment.
