ESAB Cutmaster 40 - Power Supply Specifications (CSA)

CUTMASTER 40
INTRODUCTION 0-5570
16
2.04 Power Supply Specications CSA
CM 40 120-240 VAC 1 Phase Power Supply Specications
Input Power 120 - 240 VAC, Single Phase, 50/60 Hz
1 Phase Input Power Cable CSA
Power Supply includes 9' single phase 12AWG 3/C input cable with NEMA
6-50P Plug
Output Current 15 - 40 Amps, Continuously Adjustable
Power Supply Gas Filtering Ability Particulates to 5 Microns
Inlet Pressure 90-125 PSI (6.2-8.6 bar / 620-862 Kpa)
2.04.01 Additional Power Supply Specications
CM 40 Power Supply Duty Cycle *
Ambient Air Temperature
Duty Cycle Ratings @ 40° C (104° F)
Operating Range 0° - 50° C
Rating
120 VAC Units
Duty Cycle* 30% 60% 100%
Current
27 Amps** 20 Amps 15 Amps
DC Voltage
92 93 89
208-240 VAC Units
Duty Cycle* 40% 60% 100%
Current
40 Amps 30 Amps 20 Amps
DC Voltage
135 130 135
* NOTE: The duty cycle will be reduced if the primary input power (AC) is low or the output voltage (DC) is higher than
shown in this chart.
** NOTE: 27 Amps is for a 20 Amp circuit ONLY!
DO NOT exceed a 20 Amp output setting on a 15 Amp circuit!
