APPENDIX 1: DATA TAG INFORMATION
U1
1
1
1max 1e
I
I
U
2
3Ø
3Ø1Ø
1Ø
U
0
=
X
Standard Symbols
Ø
AC
DC
Phase
NOTES:
1. Symbol shown indicates single- or three-phase AC input,
static frequency converter-transformer-rectier, DC output.
2. Indicates input voltages for this power supply. Most power
supplies carry a label on the bottom of the unit showing input
voltage requirements for the power supply as built.
3. Top row: Duty cycle values.
Duty cycle values meet or exceed the
IEC specied rating.
Second row: Rated cutting current values.
Third row: Conventional load voltage values.
4. Sections of the Data Tag may be applied to separate areas
of the power supply.
I
Art # A-14462
Output Range (Amperage/
Voltage)
Type of Power
Supply (Note 1)
Output Current Type
Rated No-
Load Voltage
Plasma Cutting
Symbol
Manufacturer's Name and/or
Logo, Location, Model and
Revision Level
Conventional
Load Voltage
Regulatory Standard Covering
This Type of Power Supply
Duty Cycle Data (Note 3)
Duty Cycle Factor
Input Power
Specications
(Phase, AC or DC
Hertz Rating)
Input Power
Symbol
Rated Supply
Voltage (Note 2)
Rated Maximum
Supply Current
Maximum Eective
Supply Current
Degree of Protection
Manufacturer's Electrical
Schematic File Number
and Revision Level
Victor Technologies Group, Inc.
2800 Airport Road
Denton, TX 76207
USA
Model: CM40 - CSA/UL
Made in Poland
CSA E60974-1
ANSI/IEC 60974-1
Class A
Ser. No.
Art. No.
Serial Number
®
