ESAB fabricator 141i User Manual

ESAB FABRICATOR 141i
INSTALLATION, OPERATION AND SETUP 3-2 Manual 0-5420
source whenever necessary to inspect or service the unit.
Do not connect an input (WHITE or BLACK) conductor to the ground terminal.
Do not connect the ground (GREEN) conductor to an input line terminal.
• Correctly installed, if necessary, by a qualied electrician.
• Correctly earthed (electrically) in accordance with local regulations.
• Connected to the correct size power point, fuse and primary supply lead based on Table 3-1. Refer to Table 3-1.
WARNING
An electrical shock or fire hazard is probable if the following electrical service guide recommendations
are not followed. These recommendations are for a dedicated branch circuit sized for the rated output
and duty cycle of the Welding Power Source.
50 / 60 Hz Single Phase Supply
Supply Voltage
115V AC
Input Current at Maximum Output
28.4 Amps
Maximum Recommended Fuse* or Circuit Breaker Rating
*Time Delay Fuse, UL class RK5. Refer to UL248
Maximum Recommended Fuse^ or Circuit Breaker Rating
^Normal Operating , UL class K5. Refer to UL248
30 Amps
30 Amps
Single Phase Generator Requirement 5 KW
Minimum Recommended Input Cable Size 12AWG
Maximum Recommended Input Cable Length 10ft (3m)
Minimum Recommended Grounding Cable Size 12AWG
Table 3-1: Electrical Service Guide
NOTE!
Welding arc outs may be experienced if an extension cord is used when STICK welding when operating
the Power Source on 95 VAC due to the lack of DC voltage at the STICK electrode.
Input Power
Each unit incorporates an INRUSH circuit. When the MAIN CIRCUIT SWITCH is turned on, the inrush circuit provides pre-charging for
the input capacitors. A relay in the Power Control Assembly (PCA) will turn on after the input capacitors have charged to operating
voltage (after approximately 5 seconds)
NOTE!
Damage to the PCA could occur if 140V AC or higher is applied to the Primary Power Cord.
Model
Primary Supply
Cord Size
(Factory Fitted)
Minimum Primary
Current Circuit Size
(Vin/Amps)
Current & Duty Cycle
MIG (GMAW/
FCAW)
STICK (SMAW)
LIFT TIG
(GTAW)
Fabricator
141i
12AWG (3.3mm
2
) 115V/20A 90A@20% 80A@35% 100A@20%
10AWG (5mm
2
) 115V/30A 140A@15% 90A@15% 140A@15%
Table 3-2: Primary Circuit Sizes to Achieve Maximum Current

ESAB fabricator 141i Specifications

General

Brand	ESAB
Model	fabricator 141i
Category	Welding System
Language	English
