ESAB FABRICATOR 141i
KEY SPARE PARTS 6-4 Manual 0-5420
6.03 Hardware List
ITEM DESCRIPTION WHERE USED Qty
1 Nut Lock, M20 25mm Dinse 2
2 Screw Hexagon, M10 × 1.5-20 ST ZP 25mm Dinse 2
3 Washer, M4, ET Lock Handle 2
Side Panel 3
4 SC PHCR M4 × 0.7-10 ST ZP Handle 2
Rear Panel 2
Front Panel 3
Side Panel 3
Door Assy 2
5 SC PHCR M4 × 0.7-16 ST BK Front Panel 2
Rear Moulding 2
6 SC PHCR ST 6G × 3/8 STBK 8 Pin Remote Socket 2
Front PCB 4
7 Nut Hexagon M4 × 0.7 ST ZP Fan 4
8 SC PHSL M4 × 0.7-30 ST ZP Fan 4
9 Nut Hexagon M12 × 1.75 ST ZP Gas Adaptor Inlet 1
10 Washer Flat, 7.91 D (M8) Wirefeeder Plate 2
11 Washer Spring, 7.91 D Wirefeeder Plate 2
12 Screw Hexagon M8 × 1.25-30 ST ZP Wirefeeder Plate 2
13 Nut Hexagon M8 × 1.25 ST ZP Wirefeeder Plate 2
14 Screw Hexagon HD 9/32 × 16 ×19 Wirefeeder Plate 2
15 Screw Skt Set M4 × 0.7 ESAB No. 4 Torch Adaptor 1
16 Screw Hexagon M6 × 1.0-10 ST ZP ESAB No. 4 Torch Adaptor 1
17 Nut Hexagon M10 × 1. 5 ST ZP ESAB No. 4 Torch Adaptor 1
Table 6-3
NOTE!
All the hardware can be purchased from local store.
