ESAB fabricator 141i User Manual

ESAB FABRICATOR 141i
Manual 0-5420 6-3 KEY SPARE PARTS
FABRICATOR 141i POWER SOURCE SPARE PARTS
ITEM PART NUMBER DESCRIPTION
1 W7006216 PCB,Power,141i
2 W7006227 PCB,Control,141i
3 W7003033 Solenoid,Valve,24VDC
4 W7006226 PCB, Remote Interface Integrated with Display, 141i
5 W7006209 Wiredrive Assy,w/ Motor,141i
6 W7004906 Feedroll retaining thumb screw
7 7977036 Feed Roll .024(0.6mm)-.030"(0.8mm) V groove Installed
8 W7004947 Fan,24VDC,4.75"x4.75"x1",141i
9 W7003010 Rectifier Bridge,1000V,50A
10 W7003215 Connector,Gas Inlet,5/8"-18UNF
11 W7006210 Dinse,Socket,141i
12 W7004983 Shoulder strap, 141i (not shown)
13 W7006224 Input Power Cable (not shown)
14 W7004942 Socket,8 Pin,w/ Harness
15 W7003053 Switch,On/Off,250V
16 W7004911 CT Sensor,Output,141i
17 W7004912 Wire Hub Assy,141i
18 W7006220 Panel, Front
19 W7006223 Panel, Rear
20 W7004922 Handle,141i
21 W7006222 Side and Top Panels (not shown)
22 W7004966 Adapter,ESAB 4,141i
23 W7004925 Guide,Inlet,.023-.045,141i
24 W7004967 Guide,Outlet,.023-.045,141i
25 W7006221 Panel,Door (not shown)
26 W7006208 Panel,Base,141i
27 870734 Knob,1/4" IDx.72" ODx.9" H
28 W7004972 Knob,1/4" IDx1" ODx0.9" H
29 W7006211 Panel,Front Control,141i
30 W7004953 Push Button Actuator
31 OTWAK/1S Screw,Locking,MIG Gun
32 W7004961 Thermistor,NTC,K45 47K,141i
33 W7004940 PCB Burnback Potentiometer
34 W7006214 PCB,Spool Gun,141i
35 W7004979 Fuse Holder,141i
36 W7006217 Fuse,10 Amp
37 W7006218 Label,Setup Chart,141i,English (not shown)
38 W7006219 Label,Setup Chart,141i,French (not shown)
39 W7006212 Inductor,141i (not shown)
40 W7004951 Spool Hub,141i
41 W7004943 Remote/Local and MIG/ Spool Gun Switch
42 W4017500 Dinse Adapter, 50mm- 25mm (not shown)
