MR & MRS OPERATION TABLES
Page 4 of 29 T-SM5f
1. PRELIMINARY INFORMATION
Part 1
Fig. 1 MR Operation Table : General Arrangement
Fig. 2 MRS Operation Table : General Arrangement
Oil filler cap
1.1 These Instructions for Use should be referred to for details of the MR and MRS general purpose, four-
section, mobile, operation tables, REF 80-085-15, 80-085-63 and 80-081-16 (serial numbers MRAB8E0000,
MRRB8E0000, MSAB8E0000 respectively, or above) and fixed base MR tables 80-085-92 and 80-085-96.
Information is also provided for earlier versions (within each section) if applicable.
1.2 This Manual covers both the MR and the MRS operation tables. The controls for the MRS tables are
fitted on an adjustable, extended control arm. There are two versions of the control arm which are both described,
however the later version only is now available. The MR table is also available in a reduced height version.
1.3 Instruction and Service Manuals should be readily accessible for reference prior to and when operating,
cleaning and servicing the Operation Table. All manuals are available from Eschmann Equipment, see inside
front cover for address details.
Related Technical Publications:-
Instruction for Use - MR and MRS Operation Tables - T-IM18
Illustrated Parts List - MR and MRS Operation Tables - T-IPL6
1.4 MR and MRS Operation Tables comply with BS6859 Part 1: 1987 (except for clause 7).
1.5 Fixed base tables should be serviced as conventional tables but check that the floor fixings are secure on
a regular (three month) basis, also check the antistatic resistor for function and connection and replace the base
seal if it becomes damaged..
