Press the and buttons to modify the shelf bevel value at each point of the shape in
each area:
• Temporal
• Mid-temporal
• Upper
• Mid-upper
• Nasal
• Mid-nasal
• Lower
• Mid-lower
Move the cursor along the shape to see the bevel profile in the zoom window.
The edger calculates the shelf bevel value to be applied between each of the four points in each area.
The bevel trajectory on the rear surface is modified in the work screen. The result can be viewed in
the zoom window.
Press the buttons and on the right of your screen to modify the value of front surface tracking.
The result can be viewed in the zoom window and the display window of the bevel trajectory on the
lens section.
Press the “cycle start” button (front face) or .
The edging cycle starts.
