Set Pan and Tilt Options
Navigate:Main Menu → Settings → Pan/Tilt
Menu Item Options Description
Pan Invert Off Invert the pan movement of the fixture.
On
Tilt Invert Off Invert the tilt movement of the fixture.
On
Pan/Tilt Feedback Off When set to On, the fixture automatically moves
back to the correct pan and tilt positions (based on
position data from the pan and tilt encoders) if the
fixture head is manually moved.
On
Pan/Tilt Limits Pan Limits Set pan and tilt limits. Fixture pan and tilt movement
is restricted to the ranges you define.
Tilt Limits
Pan Range 540 Set the range of pan movement.
630
Pan/Tilt Speed Speed 1 Set the speed (scan mode) of pan and tilt movement.
Use this setting to make fine adjustments to pan and
tilt movement to correct for misstepping when the
fixture is installed on its side (side-hung, or
"Outrig").
Speed 2
Speed 3
Speed 4
Pan/Tilt Home
Mode
Standard Set the order in which pan and tilt homing is
performed.
• Standard: The pan and tilt home procedures run
simultaneously.
• Pan First: The pan home procedure runs to
completion, then the tilt home procedure
begins.
• Tilt First: The tilt home procedure runs to
completion, then the pan home procedure
begins.
Pan First
Tilt First
Set Dimming Options
Navigate:Main Menu → Settings → Dimming
Set the dimming curve and pulse width modulation (PWM) frequency. The default value is
16kHz.
• 2.4kHz - prioritizes flawless, stepless dimming
• 16kHz - quieter than 2.4kHz and creates a beam that does not flicker when shown on
camera
