Configure the Fixture 24
Calibrate Pan and Tilt Encoders
Navigate:Main Menu → Test/Home → MagnEncoder AutoCalibrate
Navigate:Main Menu → Test/Home → MagnEncoder P/T 50%50% Set
These menu items are passcode protected and are reserved for authorized technician use only.
Contact ETC Technical Support for assistance.
These items let you calibrate pan and tilt after you have serviced the pan and tilt driver PCB,
sensor, encoder sensor, or motor.
Diagnostics Menu
View Usage Information
Navigate:Main Menu → Diagnostics → Time
Parameter Value Description
Total Fixture Hours XXXX
hours
Total running time of the fixture.
Fixture Hours XXXX
hours
Running time of the fixture from the last time that the
fixture was powered on. The counter resets after the
fixture is turned off.
Total LEDHours XXXX
hours
Total running time of the fixture LEDs.
LED Hours XXXX
hours
Running time of the fixture LEDs from the last time
that the fixture was powered on. The counter resets
after the fixture is turned off.
Reset Fixture Hours Yes This password-protected menu item resets the Total
Fixture Hours to zero. Contact ETC Technical Support
for assistance.
Once you have accessed the menu item, tap Yes to
reset the total fixture hours.
Cancel
Reset LED Hours Yes This password-protected menu item resets the Total
LED Hours to zero. Contact ETC Technical Support for
assistance.
Once you have accessed the menu item, tap Yes to
reset the total LED hours.
Cancel
View Fixture Errors
Navigate: Main Menu → Diagnostics → Error History
Displays current fixture errors. See Error Codes on page26 for information about the errors.
View Fan Speeds
Navigate:Main Menu → Diagnostics → Fan Speed
Displays the speeds of the fixture's fans in RPM.
