23 Halcyon Gold User Manual
Configure the Encoder
Navigate:Main Menu → Settings → Encoder Select
Select the position encoder.
• Photoelectric Encoder disables the Whisper Home feature so that the fixture goes
through its entire pan and tilt homing routine upon start up.
• Magnet Encoder uses the Whisper Home feature to home pan and tilt with minimal
movement and noise.
Note:
Photoelectric calibration values are stored on the Display PCB, and magnetic
calibration values are stored on the 2U PCB. If you replace either of these PCBs, you
must recalibrate the fixture. Please contact ETC Technical Support for assistance.
Reset Fixture to Factory Default Settings
Navigate:Main Menu → Settings → Restore Defaults
Tap Yes to reset the fixture to the factory default settings.
Test/Home Menu
Reset the Mechanical Positions on the Fixture
Navigate:Main Menu → Test/Home → Home
Reset ("home") all features on the fixture, including, pan, tilt, colors, gobos, etc.
Test the Fixture
Navigate:Main Menu → Test/Home → Self Test
The fixture automatically runs a self-test procedure to test each of its functions. Tap the SELF
TEST back button to end the self-test and return the display to the previous menu.
Test an Individual Channel
Navigate:Main Menu → Test/Home → Test Function
Run a self-test program on individual channels. The default value is Control. Select a different
channel to run a self-test on that channel.
Manually Set an Individual Channel
Navigate:Main Menu → Test/Home → Manual Control
Select an individual channel on the fixture and manually set the channel value. While in
Manual Control mode, all effects are canceled, the shutter opens, and the dimmer intensity is
set to 100%.
