ETC Source Four LED 3 Series - Color Mode Operation

14 Source Four LED Series 3 User Manual
Parameter DMX Value Description Comments
Curve 0–9 Incandescent
10–19 Linear
20–29 Incandescent Red Shift In Direct Mode, the fixture uses Incandescent instead of
Incandescent Red Shift.
30–39 Linear Red Shift In Direct Mode, the fixture uses Linear instead of Linear
Red Shift.
40–255 Reserved All modes use Incandescent in the range of DMXvalues
for Reserved.
Fan 0–9 Auto
10–19 Off When the fixture gets too hot, the fixture reduces the
intensity instead of turning on the fan.
20 Slow Minimum fan speed. When the fixture gets too hot, the
fixture reduces the intensity instead of adjusting the
fan.
21–248 Linear Increase in Speed When the fixture gets too hot, the fixture reduces the
intensity instead of adjusting the fan.
249 Fast Maximum fan speed (100%). When the fixture gets too
hot, the fixture reduces the intensity instead of
adjusting the fan.
250–255 Auto
Mix 0 Full Studio
1–254 Linear interpolation from
Studio to RGB
255 Full RGB
Strobe 0 No Strobe Shutter open
1–40 Dark Strobe Range is 1–40Hz.
41–80 Bright Strobe Range is 1–40Hz.
81–120 Pulse Strobe Strobe includes a fade up and fade down on each pulse.
121–160 Random Strobe Strobe pulses at random intervals.
161–200 Flicker Effect Strobe pulses at random intervals and at random
intensity levels.
201–240 No Strobe Shutter open
241–254 LEDs Off Shutter closed
255 No Strobe Shutter open
Tint 0 Neutral
1–127 Linear between +10 and 0 Tint shifts toward green (+10) as the DMXvalue
decreases to 1.
128 Neutral
129–255 Linear between 0 and -10 Tint shifts toward magenta (-10) as the DMXvalue
increases to 255.
