Specifications and Reference 29
Specifications and Reference
For current and complete compliance and specifications, see the Source Four LED Series 3
datasheet at etcconnect.com.
Environment
The Source Four LED Series 3 operates in ambient temperatures of 0°C–40°C (32°F–104°F) and
is rated IP20 (for use in dry locations only).
Fixture temperature information:
•
Maximum recommended ambient operating temperature: Ta=40°C (104°F)
•
Maximum anticipated external surface temperature: Tmax=80°C (176°F)
•
External temperature after 5 minutes of full-brightness operation at 25°C (77°F) ambient:
40°C (104°F)
•
External Temperature (steady state achieved) at 25°C (77°F): 51°C (124°F)
Weight
Component kg lb
Fixture body 6.76 14.90
Shutter barrel 2.11 4.65
Fixture body and shutter barrel 8.87 19.55
Electrical
•
Operates between 100VAC and 240VAC at a frequency of 50/60Hz.
•
Maximum power consumption is 375 W
•
Up to 4 fixtures (16 A max) may be linked via power thru connector (5 luminaires total per
circuit) when used with an R20 Relay Module, ER15 RelayModule, or Unison Echo Relay
Panel. Consult breaker trip curves when used with other equipment. Requires power from
a non-dimmable source.
•
Inrush:
-
120V: 40A
-
230V: 80A
Typical Power Consumption 100V 120V 230V
Lustr X8
Idle Power/Current 6W 0.10A 6.3W 0.09A 4.7W 0.06A
Direct at Full/Current 310W 3.15A 307W 2.6A 305W 1.35A
Daylight HDR
Idle Power/Current 6 W 0.10 A 6.3 W 0.09 A 4.7 W 0.06 A
Direct at Full/Current 345 W 3.45 A 340 W 2.85 A 330 W 1.5 A
