26 Source Four LED Series 3 User Manual
Export Fixture EventLog
The fixture routinely saves the last 50 changes to the fixture settings in an event log. The log
identifies the way in which the settings were changed (for example, whether the settings were
changed using the UI or via RDM). You can export the event log to a USB drive to aid in
troubleshooting any issues with the fixture.
1. Insert the USB drive in the USBport on the rear of the fixture (see User Interface on
page6 ).
2. Press the Menu button ( ), and then use the Intensity encoder to navigate through the
menu: Local Settings>USB>Save Events.
3. The display shows the file name to be saved (for example, s4log00.xml). Press the green
encoder (for the Save icon ) to save the file to the USB drive.
When the display returns to the USB screen, the process is complete, and the data is saved
to a file on the USB drive.
4. Remove the USB drive from the USBport.
Restore Default Settings
1. Press the Menu button ( ), and then use the Intensity encoder to navigate through the
menu: Local Settings>Restore Defaults.
2.
When the screen prompts you to confirm, press the green encoder (for the OK icon ) to
continue. The screen shows a confirmation message after default settings have been
restored. After the default settings have been restored, the DMXmode for DaylightHDR
fixtures will be Studio, and the DMXmode for LustrX8 fixtures will be 3 Ch RGB.
Update Firmware
When fixtures are connected to data, you can update firmware directly using UpdaterAtor. For
information on UpdaterAtor, see the UpdaterAtor Software QuickGuide and the UpdaterAtor
Software ReleaseNote , which you can download from etcconnect.com.
You can also update firmware using a USB drive. After you update a single fixture using a USB
drive, you can update all fixtures that are connected via wired DMX from that fixture.
Update a Single Fixture Using a USB drive
1. Visit etcconnect.com or use UpdaterAtor to get the updated firmware file for the fixture,
and then save the firmware file to a USB drive. For information on UpdaterAtor, see the
UpdaterAtor Software QuickGuide and the UpdaterAtor Software ReleaseNote , which
you can download from etcconnect.com.
2. Insert the USB drive in the USBport on the rear of the fixture (see User Interface on
page6 ).
3. Press the Menu button ( ), and then use the Intensity encoder to navigate through the
menu: Local Settings>USB>Update Firmware.
4. Use the Intensity encoder to navigate to the firmware update file, and then press the
Intensity encoder to begin the firmware update. The firmware update includes several
steps:
a. Copying the files to the fixture: A progress meter displays as the files are copied to
the fixture.
b. Verifying the files: The ETClogo displays on the top half of the screen as the fixture
verifies the files. You can safely remove the USB drive at this time.
c. Updating the fixture: The fixture installs the updated firmware files.
