Eureka E50 - Machine Preparation

18
SQUEEGEE ADJUSTMENTS
SQUEEGEE ANGLE ADJUSTMENT
Lower the squeegee.
Release and remove the clips pos. 1
Lift the regulator pos. 2 from its housing
Turn the regulator pos. 2 anticlockwise to lift the tips
of the squeegee pos. 3
Turn the regulator pos. 2 clockwise to lower the
tips of the squeegee pos. 3
SQUEEGEE PRESSURE ADJUSTMENT
To adjust the pressure, loosen the nut pos. 1 and move the wheel pos. 2:
 upwards to increase the pressure
 downwards to reduce the pressure
