CLEANING THE DETERGENT SOLUTION FILTER
The machine is fitted with a filter on the duct that comes from the detergent solution tank.
In theory, the solution located in this tank should not have any impurities as the buckets or containers used to
fill the solution are supposed to be clean; in addition there is a filter in the mouth of the tank that filters the
water.
Follow the instructions below to clean the filter:
 Bring the machine into a stop position in a flat surface area;
 Turn the machine off and remove the key;
 Close the valve;
 Unscrew the clear cup manually (pos. 3);
 Remove and clean the protective screen (pos. 2). Clean the filter housing (pos. 1) too;
 Put protective screen (pos. 2); make sure the protective screen is fitted correctly into its housing (pos. 4) of
the cap (pos. 3);
 Screw the cup pos.3;
 Open the valve.
CHECKING THE SQUEEGEE GAS SPRING AND BUSHES
Periodically check the squeegee gas spring pos. 1.
Make sure it is not damaged and that it is working
properly and applies the correct pressure to the
squeegee.
Also check the brushes pos. 2-3-4 on the squeegee
movement mechanisms.
