MACHINE PREPARATION
MOUNTING THE SQUEEGEE
Follow the instructions below to mount the squeegee to the machine:
 Park the machine on a flat surface, put the key in pos 0 and remove it;
 Put the squeegee lever in pos. 1 (squeegee in
low position).
 Fit in the squeegee (pos. A) into the squeegee
support (pos. C) ;
 Once the squeegee is fitted completely, secure
the knobs (position B).
 Fit the pipe pos. 1 on the squeegee and
connect it as shown in the picture so it makes
a loop, which will act as an anti-drop device.
