EVCO S.p.A.
EVBOX1 | Installation guide ver. 2.0 | Code 144BOX1E204
page 96 of 100
Analogue inputs Pt 1000 (1 K @ 0 °C, 32 °F)
Measurement field:
from -99 to 150 °C (from -99 to
302 °F).
Precision:
±0,5 % of scale end.
Resolution :
0,1 °C (1 °F).
Protection:
none.
Analogue inputs 4-20 mA
Input resistance:
≤ 200 .
Precision:
±0,5 % of scale end.
Resolution :
0.01 mA.
Protection:
none; maximum allowable current
at each input is 25 mA.
Digital inputs:
3 inputs, configurable via configuration parameter for NA or NC
contact (micro port, multifunction 1 and multifunction 2)
Digital inputs at 5 VDC mA (clean contact)
Power:
none.
Protection:
none.
Displays: custom 3 digit display with decimal point and function icon.
