Digital outputs:
according to model, up to 6 outputs:
-
2 SPST electromechanical relays with 30 A res. @
250 VAC (compressor and evaporator fan)
-
2 SPST electromechanical relays with 16 A res. @
250 VAC (defrosting and room light)
-
1 SPST electromechanical relay with 8 A res. @ 250
VAC (configurable through a configuration parameter
for demister heating elements, auxiliary, alarms,
door resistors, neutral area operation resistors,
condenser fan, compressor 2, defrosting 2,
evaporator fan 2, pump down valve, on/stand-by or
man in cold room; for manufacturer default for the
condenser fan).
-
1 SPDT electromechanical relay with 8 A res. @ 250
VAC (configurable through a configuration parameter
for demister heating elements, auxiliary, alarms,
door resistors, neutral area operation resistors,
condenser fan, compressor 2, defrosting 2,
evaporator fan 2, pump down valve, on/stand-by or
man in cold room; for manufacturer default for the
condenser fan).
The device guarantees reinforced insulation between each
connector of the digital outputs and the other parts of the
device.
Driver for unipolar stepper electronic expansion valves. 12 VDC, 260 mA max.
Type 1 or Type 2 actions: Type 1.
Complementary features of Type 1 or Type 2 actions: C.
Communication port: 1 door RS-485 with MODBUS slave communication protocol.
Signal buzzer and alarm: incorporated.
