TECHNICAL PARAMETERS - SINLINE RT series
PARAMETERS \ TYPE
SINLINE RT
1000
SINLINE RT
1200
SINLINE RT
1600
SINLINE RT
2000
SINLINE RT
3000
Part number
W/SRTLRT-
001K00/00
W/SRTLRT-
001K20/00
W/SRTLRT-
001K60/00
W/SRTLRT-
002K00/00
W/SRTLRT-
003K00/00
Output Power (Apparent / Active)
1)
1000 VA
650 W
1200 VA
850 W
1600 VA
1250 W
2000 VA
1650 W
3000 VA
2250 W
GENERAL DATA AND ENVIRONMENTAL
Topology
VI (line interactive)
Number of phases (in/out)
1 / 1
Housing Type
2)
Rack / Tower
Operating temperature
3)
0 ÷ + 40 °C
Storage temperature
0 ÷ + 45°C
Relative humidity during operation
20 ÷ 80 % (non-condensing)
Relative humidity during storage
20 ÷ 95 % (non-condensing)
Operating elevation
4)
< 1000 m
Protection level
IP20
Environment of installation
Office / industrial rooms with low level of pollution
Cooling
Forced, internal fans
INPUT
Rated input voltage
230 V AC
Input voltage range and tolerance
178 ÷ 281 V AC ± 2 %
Input voltage rated frequency
50 Hz
Input voltage frequency range and
tolerance
45 ÷ 55 Hz ± 1 Hz
Transfer thresholds: Mains – UPS
178 ÷ 281 V AC ± 2 %
OUTPUT
Rated output voltage
230 V AC
Output voltage range and tolerance
- normal mode
195 ÷ 253 V AC± 2 %
Output voltage range and tolerance
- battery mode
230 V AC ± 5 %
Automatic Voltage Regulation (AVR)
± 10 %
Shape of output voltage
(battery mode / normal mode)
Sine wave / same as input
Output voltage rated frequency
50 Hz
Output frequency range and tolerance –
mains operation mode
Synchronously
Output frequency range and tolerance
– battery mode
50 Hz ± 1Hz
Output voltage filtering
RFI/EMI filter, varistor TVSS
Transfer thresholds:
UPS – Mains
183 ÷ 276 V AC ± 2 %
Transfer time to battery mode
< 3 ms
Transfer time to normal mode
0 ms
Overload capability
> 105% - 15 s (UPS off)
BATTERIES AND TYPICAL RUNTIME
Internal Batteries
12 V / 7 Ah VRLA
12 V / 9 Ah
VRLA
Number of internal batteries
2
4
Maximum overall internal batteries capacity
7 Ah
9 Ah
Backup time – internal batteries
( 100 % / 80 % / 50 % Pmax)
3 / 4 / 7 min
3 / 4 / 6 min
3 / 4 / 8 min
3 / 4 / 6 min
3 / 4 / 7 min
Nominal voltage DC circuit
24 V DC
48 V DC
Internal batteries maximum charging time –
after discharging at 80 % Pmax *
4 h
MECHANICAL SPECIFICATIONS
Dimensions - Rack (H x W x D)
88 x 440 x 430 mm
132 x 440 x 460 mm
Dimensions - Tower (H x W x D)
440 x 88 x 430 mm (UPS)
450 x 260 x 430 mm (UPS + 2
supports for tower position)
440 x 132 x 460 mm (UPS)
450 x 304 x 460 mm (UPS + 2 supports for
tower position)
Net Weight
15 kg
22 kg
26 kg
28 kg
Gross Weight
17 kg
24,5 kg
28,5 kg
30,5 kg
Transport Dimensions (H x W x D)
197 x 547 x 545 mm
247 x 547 x 595 mm
Position in which devices transported
Horizontal
Output cables maximum length
< 10 m
