TECHNICAL PARAMETERS - SINLINE RT XL series
PARAMETERS \ TYPE
SINLINE
RT XL 650
SINLINE
RT XL 850
SINLINE
RT XL
1250
SINLINE
RT XL
1650
SINLINE
RT XL
2250
SINLINE
RT XL
3000
Part number
W/SRTXR
T-
000K65/00
W/SRTXR
T-
000K85/00
W/SRTXR
T-
001K25/00
W/SRTXR
T-
001K65/00
W/SRTXR
T-
002K25/00
W/SRTXR
T-
003K00/00
Output Power (Apparent / Active)
1)
650 VA
650 W
850 VA
850 W
1250 VA
1250 W
1650 VA
1650 W
2250 VA
2250 W
3000 VA
3000 W
GENERAL DATA AND ENVIRONMENTAL
Topology
VI (line interactive)
Number of phases (in/out)
1 / 1
Housing Type
2)
Rack / Tower
Operating temperature
3)
0 ÷ + 40 °C
Storage temperature
0 ÷ + 45 °C
Relative humidity during operation
20 ÷ 80 % (non-condensing)
Relative humidity during storage
20 ÷ 95 % (non-condensing)
Operating elevation
4)
< 1000 m
Protection level
IP20
Environment of installation
Office / industrial rooms with low level of pollution
Cooling
Forced, internal fans
INPUT
Rated input voltage
230 V AC
Input voltage range and tolerance
178 ÷ 281 V AC ± 2 %
Input voltage rated frequency
50 Hz
Input voltage frequency range and
tolerance
45 ÷ 55 Hz ± 1 Hz
Transfer thresholds: Mains – UPS
178 ÷ 281 V AC ± 2 %
OUTPUT
Rated output voltage
230 V AC
Output voltage range and tolerance -
normal mode
195 ÷ 253 V AC ± 2 %
Output voltage range and tolerance -
battery mode
230 V AC ± 5 %
Automatic Voltage Regulation (AVR)
± 10 %
Shape of output voltage (battery mode /
normal mode)
Sine wave / same as input
Output voltage rated frequency
50 Hz
Output frequency range and tolerance –
mains operation mode
Synchronously
Output frequency range and tolerance –
battery mode
50 Hz ± 1Hz
Output voltage filtering
RFI/EMI filter, varistor TVSS
Transfer thresholds: UPS– Mains
183 ÷ 276 V AC ± 2 %
Transfer time to battery mode
< 3 ms
Transfer time to normal mode
0 ms
Overload capability
> 105% - 15 s (UPS off)
BATTERIES AND TYPICAL RUNTIME
Internal Batteries
12 V / 7 Ah VRLA
12 V / 9 Ah
VRLA
12 V / 7 Ah
VRLA
Number of internal batteries
2
4
2x 4
Maximum overall internal batteries capacity
7 Ah
9 Ah
7 Ah
External battery modules (EBM)
Yes
Maximum number of EBMs
1
Backup time – internal batteries ( 100 % /
80 % / 50 % Pmax)
3 / 4 / 7
min
3 / 4 / 6
min
3 / 4 / 8
min
3 / 4 / 6
min
3 / 4 / 7
min
3 / 4 / 7
min
Backup time – internal batteries + EBM
(100% / 80% / 50% Pmax)
27 / 37 / 68
min
19 / 26 / 48
min
15 / 20 / 37
min
10 / 14 / 26
min
9 / 11 / 19
min
7 / 10 / 20
min
Nominal voltage DC circuit
24 V DC
48 V DC
Internal batteries maximum charging time –
after discharging at 80 % Pmax *
4 h
Internal batteries + EBM maximum
charging time – after discharging at 80 %
Pmax *
12 h
