2.6. DISPLAYS
2.6.1. Single Server with a Single Controller, Standard Setup
Required equipment:
 DreamCatcher Server
 DreamCatcher Controller
 2x Displays or Optional Touch Displays
DreamCatcher Server 1
DreamCatcher Controller 1
Monitor Touch Monitor
DVI DVI
DVI Display Port 1
USB
USB B
USB A
Figure 2-7: Single Server with a Single Controller - Standard Setup
2.6.2. Single Server with Dual Controllers, 4 Monitor Setup
Required equipment:
 DreamCatcher Server
 2x DreamCatcher Controller
 2x Standard Displays
 2x Displays or Optional Touch Screen Displays
